Williams System Any 11 B cpu mpu Flat Rate circuit board repair

1987 WILLIAMS F-14 TOMCAT PINBALL MACHINE PIN BALL Coin Op

Offered for your consideration, is this nice F-14 Tomcat pinball. Factory mylar, playfield is really nice 8/10. Plastics are all nice. Cabinet 8/10, light normal wear. Has coin mechs, no lock bar holes. The boards look clean. Most, if not all, light bulbs work. I don’t see any not working, but I may have missed something. A few minor issues. When you turn it on, it wants to go into Factory Settings mode. If you turn it on and off and on again quickly, it starts up as normal, attract mode works as it should and the game plays without issue. When you start a game, it will sometimes kick out 2 balls. Also, occasionally the strobe lights wont turn. They light up and spin sometimes, other times, they may just light up and not spin. Otherwise, the game plays, scores, functions as it should. The video will show it in attract mode. I believe these issues are all minor and could be fixed easily by someone with pinball knoedge. Photos are of the exact item you’ll receive. 2 steps, easy load out. I’m not able to lift/move this. Weekdays (during the early afternoon) are best for meeting you (or your mover). All sales are final.

WILLIAMS BRAM STOKER’S DRACULA PINBALL MACHINE COLOR DMD LEDs

Classic Williams machine in great condition. Everything works as it should. All bulbs changed to high quality LEDs. Cabinet is in great shape with a few nicks and scratches Playfield cleaned, and new rubbers installed. A Color DMD, Coffin and lit upper hole mystery mods installed.

Williams D-12158 & D-12313 System 11 Backbox Interconnect Board

This PCB is a replacement Backbox Interconnect Board suitable for most Williams System 11B & 11C machines with part numbers D-12158-xxx and D-12313-xxxxx. The boards are supplied as a Complete Assembly, or, as a Kit with the IC Sockets and Fuse Clips already fitted. Also included are all the Header Connectors, Opto Isolator ICs, machine specific resistors and jumpers relevant to the Backbox selected. Whilst each board uses different headers, a complete set is supplied to allow future proofing if the board is changed for a different machine. Please note:- Doing so will probably require different values and/or numbers of resistors and/or jumpers suitable for the’new’ game. For D-12158-xxx machines, (Taxi & Swords of Fury), the relevant Headers, J4, J11 and J12, are common to the corresponding game sockets with misaligned fitting prevented by the Key pin. Pin 1 of J4 is Pin 1 of the corresponding socket and Pin 1 of J11 & J12 are marked on the board for which ever version is to be used. See image for details. For the self assembly Kit, sel ect the relevant machine from the drop down box and we will send all the parts required for that machine. For both the complete PCB and Kit, we will also include a parts location list to show where each component is fitted. Whilst every effort is made to ensure accuracy of the information supplied, the assembly of the board is at your own risk. You are advised to exercise caution and to check and confirm the information and parts supplied are correct. No responsibility will be accepted for any damage to you or your game. It is not added by us. See Listing for details.

WILLIAMS BLACK KNIGHT DRIVERBOARD Repair Service Flat Rate

Pinball Services want you to know we are doing what we can to remain business as usual while maintaining due diligence to prevent ANY issues from Viruses. This means using bleach an other remediation tools to clean while we work to keep our team, an our customers, safe an well. UNSURE IF THIS DRIVERBOARD SERVICE WILL CORRECT YOUR PROBLEMS? TECHS WILL ANSWER YOUR QUESTION REGARDING GETTING A WILLIAMS MACHINE 100%. Offering Factory Trained Repair/Professional upgrade Services for ALL Williams BLACK KNIGHT. PART# D-7997 AND 1B-2001-131-2. YOUR BOARD WILL HAVE INSTALLED. CERAMIC RESISTORS /40 PIN CONNECTOR. ALL WEAK COMPONENTS REPLACED. FINAL TESTED SEVERAL HOURS. ALL 22 SOLENOID PORTS TESTED. ALL 64 SWITCH POSITIONS TESTED. ALL 64 LAMP POSITIONS TESTED. CERAMIC LAMP RESISTORS INSTALLED. SEND IN YOUR GAME’S NON WORKING DRIVERBOARD OUR TECHNICION WILL SERVICE AND TEST ALL FUNCTIONS AND RETURN WITHIN 5 DAYS AFTER RECEIVING. LIST OF COMMON PROBLEMS THE DRIVERBOARD NEEDS SERVICE. NO FLIPPERS/FLIPPERS ON IN GAME OVER. ALL COILS LOCK ON DURING POWER UP. ALL COILS POP MOMENTARILY AT POWER UP. 1 OR MORE COILS LOCK WHEN POWER UP. POP BUMPER OR SLING COIL LOCKS WHEN GAME IS STARTED. MORE THAN ONE SWITCH REGESTERS WHEN ONE SWITCH IS ACTUATED. UNABLE TO START A GAME. SEVERAL LAMPS ARE EXTREAMILY BRIGHT ON PLAYFIELD. SEVERAL LIGHTS ARE NOT WORKING. ALL COMPUTER CONTROLLED PLAYFIELD LIGHTS NOT WORKING. NOTIBLE HEAT AND SCORCHING IN THE LOWER RIGHT CORNER OF BOARD. Keep your game original.

Williams Phoenix Pinball Machine Send in Board Repair service

Your friends at Pinball Services want you to know we are doing what we can to remain business as usual while maintaining due diligence to prevent ANY issues from Viruses. This means using bleach an other remediation tools to clean while we work to keep our team, an our customers, safe an well. Offering Factory Trained Repair/Professional Service. Electronic circuit boards, cabinet harnesses, Playfield wiring. WILLIAMS PHOENIX SYSTEM 3 COMBO 3 BOARD CPU, DRIVERBOARD, POWER SUPPLY, FLAT RATE SERVICE. PHOENIX, DISCO FEVER, HOT TIP AND OTHER SYSTEM 3 GAMES. THIS REPAIR SERVICE RESTORES CORRECT SYSTEM OPERATION & RELIABILITY TO WILLIAMS SYSTEM 7 BOARDS. There has never been a Pinball SYSTEM so vilified, scrutinized, ostracized and generally dumped on than the Williams CPU/ MPU/DRIVERBOARD/POWER SUPPLY BOARDS Yet, the SYSTEM is still here and can usually be rescued. There is a good reason why they are still around after 40 Years. They were designed to take incredible abuse. With FAT traces and rugged pads they can be repaired dozens of times in the hands of many’techs’ and still survive. NOBODY WILL SAY A WILLIAMS BOARDSET IN A 35 YEAR GAME THAT IS ORIGINAL, UNDAMAGED, OR WITH MINIMAL OVERHEATING CANNOT BE REPAIRED TO WORK RELIABLE! AS A PINBALL OWNER WITH A NON WORKING SYSTEM YOU HAVE A CHOICE TO HAVE YOUR ORIGINAL WILLIAMS 3-4-6-7 SYSTEM SERVICED & RESTORED TO RELIABILITY. SERVICING THESE THREE BOARDS WILL ASSURE A GAME THAT WAS RUNNING AND SHUT DOWN WILL BOOT UP AGAIN. New technology installed into vintage technology IS NOT RECOMMENDED WITH CLAIMS OF ALTERED CIRCUITS AND TIMING CLOCKS, VOLTAGE RESET CHANGES DON’T MAKE A BETTER GAME OR SYSTEM AS THESE AFTERMARKET BOARDS MIMIC THE SAME OPERATION NO BETTER. TE IDEA IS TO GET A GAME UP AND WORKING AGAIN CHOOSING SO JUST A MATTER OF OPINION AND DOES NOT MAKE A BETTER OR MORE RELIABLE SYSTEM RATHER A CLONE WITH IT’S POTENTIAL UNDISCOVERD PROBLEMS, SEASONED TECS DON’T WANT TO DISCOVER NEW PROBLEMS THAT DON’T EXIST WITH ORIGINAL WILLIAMS BOARDS TEC SUPPORT IS USUALLY WEAK WITH AN AFTERMARKET. THE CLOCK CHIP BECAME OBSOLETE AND WAS NEVER A PROBLEM SYSTEM WISE IN FACT SYSTEM 3 AND 4 WILLIAMS CAN BE REBUILT TO BE RELIABLE AGAIN JUST THE SAME. WILLIAMS AS WITH ALL OTHER MANUFACTURERS STARTED USING THE NEW MOTOROLA 6808 AROUND 1979 WHICH WAS A SIMPLER REVISED DESIGN USING LESS PARTS AND OPERATED THE SAME WAY AS A 6800 NEARLY THE SAME AS A 6802 EXCEPT IT HAS AN INTERNAL RAM. A TIP 107 DRIVES A LAMP ROW AND SO DOES A TIP 42 AND A 27 OHM RESISTOR, AN INTERCONNECT OF 40 PINS THAT CONNECT THE BOARDS IS THERE FOR SEPARATE CIRCUIT BOARD SERVICE. WROTE A PROGRAM TO TEST THE CPU BOARD WITHOUT A DRIVERBOARD ATTACHED! AND IF THE DRIVER BOARD WAS FAULTY IT WOULD BE USELESS AND NOT ALLOW THE TEST TO CHECK THE WORKING CPU SIDE. THE RESET CIRCUIT IS BASED ON 12v THE SAME 12v THAT CREATES 5v A WORKING POWER SUPPLY WILL NEVER CAUSE A RESET PROBLEM FOR ANY ORIGINAL 3-4-6 OR 7 GAME. THE 40 PIN CONNECTOR IS QUICKLY REPLACED WITH TODAY’S MOLEX ADVANCED TECHNOLOGY WHO MAKE CONNECTORS FOR INDUSTRY, MARINE, DEFENSE AUTOMOTIVE, INDUSTRIAL, AND MEDICAL. AFTER REPLACEMENT OF THE 40 PIN CONNECTOR WITH MOLEX PRODUCTS THE CONNECTION PROBLEMS ARE SOLVED. THERE ARE NO SERVICE BULLETINS REGARDING THE ABOVE BECAUSE THE SYSTEMS DID NOT REQUIRE THESE MODIFICATIONS , IF YOUR GAME HAS ORIGINAL BOARDS ITS TIME FOR UPKEEP EVEN IF THEY ARE WORKING THEY ARE 30-40 YEARS IN THE MAKING AND NEED MAINTENANCE & SERVICE. JUST LIKE A CLASSIC CAR. WHICH RESTORES THE WILLIAMS FACTORY DESIGNED SYSTEM BOARD SET BACK TO ARCADE RELIABILITY FOR YEARS TO COME. BEWARE OF COPY REPRODUCTION BOARDS THAT ATTEMPT TO MIMIC THIS GREAT SYSTEM THERE IS RARELY A PROBLEM RESTORING A ORIGINAL Cpu, Driverboard, and Power Supply boards BACK TO ITS FORMER GLORY, NO NEED TO LOCK IN WITH A PROTOTYPE BOARD WITH SOCKETS AT EVERY CHIP WITH AN OVER 280 PIN INTERCONNECTS OF UNDERSOLD IC’S WILLIAMS SOLDERED IC’S ON THEIR BOARDS FOR THAT REASON. WE HAVE THE PROFESSIONAL TOOLS TO EASILY REMOVE AND REPLACE ANY SIZE CHIP WE DO NOT INSTALL SOCKETS INTO OUR BOARDS WE SERVICE, REPLACEMENT CHIPS ARE SOLDERED IN PLACE AS FACTORY STANDARD. AFTERMARKET BOARDS HAVE A SOCKET AT EVERY CHIP MAINLY BECAUSE THEY CANNOT WITHSTAND DE SOLDERING HEAT AS THE TRACES AREN’T AS RUGGED AND WILL EASILY LIFT FROM THE BOARD. WE DO NOT OFFER REPAIR TO AFTERMARKET BOARDS FOR THIS REASON. WILLIAMS LATER DROPPED ALL SOCKETS ON THE DRIVERBOARD BECAUSE IT WAS NOT RELIABLE PRACTICE. IF NEW BOARDS ARE BEING CONSIDERED THEN WE SUGGEST GETTING A FRESHLY MANUFACTURED MACHINE. ORIGINAL WILLIAMS BOARDS ARE RUGGED AND CAN WITHSTAND DOZENS OF REPAIRS. THIS SERVICE IS FOR ALL WILLIAMS 3-4-6-7 BOWLER AND PINBALL GAMES: Alien Poker Blackout Baracora Black Knight Blackout Pokerino Scorpion Solar Fire Starlight Stellar Wars Time Fantasy Contact Cosmic Gun Defender Disco Fever Fire Power Fire Power II Flash Gorgar Hot Tip Joust Jungle Lord Laser Ball Laser Cue Lucky Seven Phoneix Pharaoh Time Warp Tri-Zone Varkon Warlock World Cup. Big Strike Triple Strike Pompei LIST OF COMMON PROBLEMS THE SYSTEM NEEDS SERVICE. TWO RED LIGHTS LOCKED ON. ETHER ONE UPPER RED LIGHT OR ONE LOWER LIGHT IS LOCKED ON AFTER DIAGNOSTIC BUTTON IS PRESSED. GAME SHUTS DOWN DURING GAMEPLAY OR BY ITSELF. 1 POP BUMPER LOCKED ON OR INTERMITTENT GAMEPLAY CONTINUES AFTER DRIVERBOARD REPLACEMENT. SCORING NUMBER COUNT OFF AND OR INTERMITTENT SCORE FUNCTION. PROGRAMMING LOST AFTER POWERING OFF OR GAME IS LOCKED IN ADJUSTMENT FAILURE WITH A CODE DISPLAYED IN PLAYER 1 SCORE. GAME DOES NOTHING AND BOTH RED LIGHTS LOCKED ON. Keep your game original.

WILLIAMS GETAWAY HIGH SPEED 2 PINBALL MACHINE LEDs

Desirable machine in excellent condition. Everything works as it should. Playfield was cleaned and is in beautiful condition. All bulbs changed to high-quality LEDs. All new flipper mechanisms installed. New rubber rings, posts etc installed on the playfield and no broken plastics. Donut Heaven Mod and S upercharger sign with moun tains Mod installed.

1971 Williams Action Baseball Machine Pitch And Bat Pinball Arcade

Some things power in and make some noises. Has all the manuals, legs and some extra parts. Back glass is in great condition.

1952 Williams Super World Series Baseball Pinball Pitch & Bat Arcade Works

1952 Williams Super World Series Baseball Pinball Pitch & Bat Arcade Works. With that said the game is in working order and I attempted to take a video but it was pretty difficult when you are the only one holding the camera, pitching the ball and swinging the bat, so the video is not the best, but you will get the idea and see that it works. To see it working. The machine has wear and it is far from perfect as there is playfield wear, backglass wear and some parts of the cabinet have been painted or touched up. The wood legs are not the correct legs, but they do work for the machine. The game is set up for free play and it does have the back service door and key for it. Please look at all pictures. Because grading is subjective to each individual, it is important that you review all pictures closely. If there is some damage or missing parts I will do my best to always mention what I see. Listing and template services provided by inkFrog.

Williams Widebody Demolition Man Pinball 1994, Flawless Play Expert Restoration

Williams Widebody Demolition Man Pinball 1994 – Expertly Restored, Flawless Play. This is a 5-ball machine, renowned for its fast multiball play, numerous ramps, and combos. 1 to 4 players, featuring 3 flippers controlled by trigger handles or traditional flipper buttons, your choice. 5 multiball modes, all leading to a slew of different jackpots. 5 Cryoclaw choices, collect them all to enable an exciting “Demolition Time” wizard-mode multiball fiesta. This is probably the best multiball game ever. Guaranteed excitement and smiles from all players, regardless of skill level. The best bang for your buck in a Widebody Williams, other titles can cost more than double. 6 high scores of 3 varieties are retained to immortalize players. The 4 regular high scores reset after 250 games (adjustable). Playfield in excellent condition, was cleaned and waxed on a regular schedule to prevent wear. 24 photos, full disclosure, nothing to hide. Perfectly Adjusted Switches: Every switch is meticulously cleaned and calibrated. Operational Lamps and Flashers: All lights are fully functional. Strategically Added LEDs: High failure vibration points fortified with LEDs. Vintage Look: General illumination retains incandescent lamps for an authentic feel. Enhanced Color Scheme: Added vibrant colors to the stock design e. Blue lamps for quick freeze ramp. Clean white LEDs on clear lenses e. Stand-ups to avoid that yellowish look. The different colored LEDs are diode adjusted for uniform illumination. All lenses cleaned under playfield. Cryoclaw Identification: Colored bulb caps for easier selection of each claw option. Upgraded Rubbers: Replaced original black rubber rings with white. This is a very clean machine, no need for black rubbers to hide dirt. Rebuilt Flippers & Coils: Strong, rebuilt flippers, new bushings, springs, stops, and EOS switches. Most machine coils are original Williams brand. New sleeves, and stops throughout. Everything mechanical pops with authority. Ergonomic Design: Very unique feature, reducing palm discomfort that normal flipper buttons can cause during long play sessions. Easier and more controlled nudging and shaking. Fastened with strong steel backing plates for solid cabinet attachment. Very rugged and ergonomic, designed for an extreme commercial environment. Williams hit it out of the ballpark with this feature. Using the handles enables “Easter eggs”, extra bonus points, and secret jackpots. Two buttons per handle. Adjusted for hair-trigger response. Also has traditional flipper buttons for those who prefer them. Pinball-Pro Subwoofer with Coaxial Backbox Speakers: Enhanced sound quality without distortion at high volume. Sounds and feels amazing; a truly tactical experience for an explosive soundtrack loaded with special effects. Original speakers and woofer included with spare parts. Profanity ROMs, Sound Board Cap Mod : Improves overall audio experience. Contains the infamous profanity, or “curse” sound-ROMs with amusing R-rated movie chatter (vulgarity mode can be disabled). Professional Restoration: Leveraged 40 years of electrical engineering expertise. Machine has been here for 20 years, now downsizing. Skill-Shot Ramp Modification: Added clear plastic piece to prevent ball from going airborne and stuck out of play. Cooling Fans: Slow and quiet fused fans installed for gentle heat extraction from cabinet and backbox, ensuring longevity. Can be easily unplugged if desired. Rebuilt Power Board: Caps, rectifiers, etc. Key power paths on back of power board beefed up with copper wire mods for reduced resistive losses, greater efficiency (less waste heat) and snappier game play. Many connectors replaced with gold high-quality crimp-on Molex style where needed. Socketed CPU Board Switch Chip: Easier maintenance and repairs. New Tempered Glass: No scratches. Spotless inside and out. New Eyeball and Matchbox Cars: From the movie, enhancing the thematic experience. These are the official cars, not some random replacements. Cabinet Condition: Great overall, minor scratches and touchup needed on the door. Repainted legs with cabinet protectors. New adjustable feet and rubber pads. Ramps and Plastics: A few minor cracks, fully disclosed in photos. Does not affect game play. All the metal plastic protectors are installed, along with added sling shot plastic protectors at several locations on the playfield. Display: Last column of the high voltage display is out, not noticeable during regular play. Almost every possible wearable part is covered. Included Spares: A complete set of 5 new stand-up targets, used good Cryoclaw motor assembly, trigger switches, new elevator motor assembly, new ACmag metal assembly, fuses, switches of all types, various cabinet circuit boads, 8 new spare eyeballs, no fluid leaks, full set of lamps and rubbers, super jet parts, optos, 3 flipper rebuild kits with bushings and EOS switches, springs, sling shot parts, numerous plastics, replacement coils, stops, springs, and sleeves, claw e-magnet. Special adjustments tools, cleaning supplies, full documentation and receipts. Too much to list here, see photos. Note: backbox lock was reinstalled after the photos were taken. Avoid Hidden Costs: Comprehensive spare parts included to avoid future expenses and downtime, wasting your valuable time searching for difficult or almost impossible to find components. Many machine-specific parts included. You will not be disappointed. Any extra moving expenses are your responsibility, big 350 pound machine. I will assist in disassembly for moving, but can’t lift. Backbox folds down and legs come off for transportation. Free play only, incomplete coin mech. 115 volt, 10 amp, 60 hertz transformer input configuration. Note: machine was reimported back from Germany where it was well cared for, has 230 volt label inside. This is a great opportunity to own a meticulously restored and maintained Demolition Man pinball machine, with numerous enhancements. This is the perfect centerpiece for any gameroom, offering years of play and enjoyment without spare parts anxiety. Pinball is becoming more popular every day, and prices keep rising. Don’t miss out on this incredible machine! This comprehensive listing shows you my professional attention to details.
