Pinball Machine PD-16_v2 Multimorphic PD-16 V2 Board (2029) – New/Old Stock. The PD-16 is modular 16-circuit board that’s generally used to control high-current devices on a pinball machine, such as coils, motors, magnets, etc. It can be driven directly by a. Or indirectly (through a high-speed RS-485 master device) by various other microcontroller-type devices. Each PD-16 driver board has an RS-485 serial interface so that it can chain to other drivers boards. Therefore, you can use as many driver boards as your application requires. Further, since the serial interface will continue to work at distances well over 10 feet (100 feet even), you can locate the boards in the backbox, under the playfield, or anywhere else in your machine. The Power Driver 16 has 16 n-channel MOSFETs for control of up to 16 unique features. The transistors are grouped into two banks of 8. Each bank contains a DC power input, and a fused (5x20mm) power output. Each circuit has a local flyback diode to protect against back-EMF. We do not have control over these rates. However, orders placed through our websites are handled directly by Automated Services. If you have any questions, please give us a call to talk to a live person!
